4Banger LED Pods: HXB Wide Beam
1/14
4Banger LED Pods: HXB Wide Beam

4Banger LED Pods: HXB Wide Beam

$583.00
Shipping calculated at checkout.
Details

Introducing the Morimoto 4Banger HXB Wide - the ultimate off-road LED lights designed to revolutionize your driving experience! Since 2008, Morimoto has been the go-to choice for lighting upgrades in the automotive aftermarket, consistently delivering unrivaled performance, reliability, and style. Our HXB Wide Beam lights are not just powerful; they're SAE-Compliant, boasting an 80% brightness advantage over the competition. With cutting-edge Osram HX Boost LEDs and precision optics, these lights offer superior width, intensity, and control, making them the ultimate off-road LED fog lights. But it's not just about performance; it's about fitment too. The 4Banger HXB is 30% smaller than alternatives, ensuring an OEM+ fitment with Morimoto's mounting kits, available for popular trucks. For a street-legal fog light, our HXB Wide beam models are SAE J583 compliant. Don't settle for less; upgrade to the Morimoto 4Banger HXB Wide and experience off-road lighting like never before!

TECHNICAL SPECIFICATIONS

  • Note : These specifications are per pod / each!

  • Intensity (White) : 21,000 Cd (Post Warm-Up) (210lux @ 10m)

  • Intensity (Yellow) : 14,700 Cd (Post Warm-Up) (147lux @ 10m)

  • Input : Integrated Deutsch DT 2-Pin

  • Power (stabilized) : 42w

  • Current : 3.2A @ 13.5V DC

  • Peak Luminosity (raw) : 3,000lm

  • Dimensions : 82mm W, 67mm H, 60mm D

  • Hardware : M6x1.0 8mm (4Banger to U-Bracket), M10x1.5 20mm (U-Bracket base)

  • Color : 2700K (Yellow) or 5700K (White)

  • Light Source : 3x Osram HX Boost (5700K)

  • Material : Makrolon LED PC (Lens), Powdercoated Die Cast Aluminum (Housing)

WHAT’S INCLUDED

  • LED Pods : 2x (One Pair) Morimoto 4Banger HXB SAE Wide Beam (White or Yellow)

  • Hardware : 2x M10x1.5 SS Carriage Bolts, 2x M10 SS Washers, 2x M10 SS Lock Nuts, 8x M6x1.0 SS Screws

  • Optional Brackets : 2x Top, Bottom, or Flush Mounts

  • Optional Wiring : 1x Morimoto Switched Relay Harness or 2x Pigtails

  • Optional Covers : 2x Rubber Blackout Covers
